Features:

1.     Compatible with Socapex "419" and Veam "VSC" connectors

2.     Rugged die-cast aluminum alloy shell with black non-conductive finish

3.     Hard gold-plated contacts for solder termination

4.     Integral compression-type strain relief accommodates a wide range of cable sizes

5.     M40 metric cable gland with two bushing sizes:
M40-25: 18–25 mm cable diameter
M40-30: 22–30 mm cable diameter
Unless otherwise specified by the customer, M40-30 is supplied as standard.

Specifications:

• Rated Current / Voltage: AC 20A / 250V
• Operating Limit Voltage: AC 400V
• Insulation Resistance: 500 MΩ
•  Contact Resistance: < 3 mΩ
• Operating Temperature: -20°C to +85°C
• Withstand Voltage: 1,800 VAC / 1 min
• Mating Durability: 5,000+ cycles
